Variomatic Screeds
ABG Wheeled Pavers | Tracked Pavers
Secured versatility
Single tamper Variomatic screed with a paving width of 2.5-7.5m.
Available for: ABG 4370 | ABG 5320
The VB30 tamping and vibrating screeds feature the robust screed guide system, hydraulic screed crown, and extend to double the basic width (1.5m-3.0m). Screed extensions can be fitted to increase the paving width even further up to 4.0m.
Available for: ABG 2820
Single tamper Variomatic screed with a paving width of 1.8-4.5m.
The screed features a tiltable walkway, mechanical or hydraulic screed crown and zero-daily maintenance with lifetime lubricated tamper and vibration bearings. Two possible screed extensions are available: 52.5 cm and 27.5 cm, with the latter allowing machine transportation without disassembling extensions and end-gates.
Available for: ABG 2870 | ABG 2820
Single tamper Variomatic screed with a paving width of 2.5-9m.
Available for: ABG 6870 | ABG 8820, ABG 7820, ABG 7820L, ABG 6820, ABG 6820L, ABG 6720L, ABG 4820
Single tamper Variomatic screed for special crown profiles with a paving width of 2.5-9m. ABG screeds for special crown profiles are the perfect choice when creating special profiles in the road surface. With two additional articulated sections which are adjustable upwards or downwards by 10% (5.7°), they create the possibility to pave irregular profiles with greater ease, reduced material wastage and at a lower cost.
Available for: ABG 6870 | ABG 8820, ABG 7820, ABG 6820, ABG 4820
Single tamper Variomatic screed with a paving width of 3.0-9.0m and up to 10m for tracked pavers.
Available for: ABG 6870 | ABG 8820, ABG 7920, ABG 7820, ABG 7820L, ABG 7320, ABG 6820, ABG 6820L, ABG 6720L, ABG 4820
Single tamper Variomatic screed for special crown profiles with a paving width of 3.0-9.0m. ABG screeds for special crown profiles are the perfect choice when creating special profiles in the road surface. With two additional articulated sections which are adjustable upwards or downwards by 10% (5.7°), they create the possibility to pave irregular profiles with greater ease, reduced material wastage and at a lower cost.
Available for: ABG 6870 | ABG 8820, ABG 7820
Double tamper Variomatic screed with a paving width of 2.5-9.0m. The best partners for paving thick layers, ABG Variomatic screeds with dual tamper bar offer higher pre-compaction to optimize the cost-effectiveness of your projects. The double tamper technology delivers a 5-7% higher degree of compaction and can achieve up to 98% Marshall density. It also provides the best possible even surface due to the feeding effect of the first tamper.
Available for: ABG 8820, ABG 8820L, ABG 7820, ABG 7820L, ABG 6820
Double tamper Variomatic screed for special crown profiles with a paving width of 2.5-9.0m. The best partners for paving thick layers, ABG Variomatic screeds with dual tamper bar offer higher pre-compaction to optimize the cost-effectiveness of your projects. The double tamper technology delivers a 5-7% higher degree of compaction and can achieve up to 98% Marshall density. It also provides the best possible even surface due to the feeding effect of the first tamper. ABG screeds for special crown profiles are the perfect choice when creating special profiles in the road surface. With two additional articulated sections which are adjustable upwards or downwards by 10% (5.7°), they create the possibility to pave irregular profiles with greater ease, reduced material wastage and at a lower cost.
Available for: ABG 8820, ABG 7820, ABG 6820
Double tamper Variomatic screed with a paving width of 3.0-9.0m. The best partners for paving thick layers, ABG Variomatic screeds with dual tamper bar offer higher pre-compaction to optimize the cost-effectiveness of your projects. The double tamper technology delivers a 5-7% higher degree of compaction and can achieve up to 98% Marshall density. It also provides the best possible even surface due to the feeding effect of the first tamper.
Available for: ABG 8820, ABG 8820L, ABG 7820, ABG 7820L, ABG 6820
Double tamper Variomatic screed for special crown profiles with a paving width of 3.0-9.0m. The best partners for paving thick layers, ABG Variomatic screeds with dual tamper bar offer higher pre-compaction to optimize the cost-effectiveness of your projects. The double tamper technology delivers a 5-7% higher degree of compaction and can achieve up to 98% Marshall density. It also provides the best possible even surface due to the feeding effect of the first tamper. ABG screeds for special crown profiles are the perfect choice when creating special profiles in the road surface. With two additional articulated sections which are adjustable upwards or downwards by 10% (5.7°), they create the possibility to pave irregular profiles with greater ease, reduced material wastage and at a lower cost.
Available for: ABG 8820, ABG 7820
Quick coupling system for fast addition/removal of extensions
Fast screed heating - three independent circuits and 2 heating bars per segment
Precise electric thermo-controlled heating with automatic temperature adjustment
Intuitive screed control unit
Very stable screed guide system
Hydraulic height adjustment
Ease of lubrication
Grade and slope controls
Dual tamper bar variant for higher pre-compaction of thick layers
Special profiles variant
The versatile fixed screeds from ABG have proved their effectiveness across a host of paving projects all over the world.
